Specifications:

• (Viewing Angle): 50/70/70/70
• Usage: Monitors
• (Technology): a-Si TFT-LCD
• size: 6.5"inch
• (Resolution): 800*480 WVGA
• Remark: test one by one before ship
• (Pixel Pitch): 0.05975*0.1598 mm
• (Pin of Singnal Interface): 50 pins
• Part number: AT065TN14
• Output voltage: 19V
• Output Type: AC
• (Outline): 155.20* 89.40*5.50 mm
• Model Number: AU
• (Life Time of Lamp): 20K Hours
• (Input Current): 4/2/0.6/0.6mA (DIDD/AIDD/IGH/IGL)
• (Drive-screen voltage): 3.3/10.4/16.0/-7.0V (DVDD/AVDD/AVDD/VGL)
• (Display scale): 17:9
• (Display Area): 146.2*78.7
• Connection: Plug In
• Brand Name: Garmin
• (Active Area): 143.4*76.7 mm
