Specifications:

• Accuracy (flow--pulse output): 10~200L/min±3%
• Allowable withstand pressure: water pressure below 1.75M pa
• Brand Name: Shanwen
• DIY Supplies: ELECTRICAL
• Humidity range: 35% to 90% RH (no frosting)
• Load capacity: ≤10 mA (DC 5V)
• Maximum operating current: 15 mA (DC 5V)
• Measurement Range: as shown
• Minimum rated working voltage: DC 5V-24V
• Model Number: 652F9FF600447-DN40
• Operating temperature range: ≤80°C
• Operating voltage range: DC 5~18 V
• Origin: CN(Origin)
• Output fall time: 0.18μS
• Output pulse duty cycle: 50±10%
• Output pulse high level: >DC 4.5 V (input voltage DC 5 V)
• Output pulse low level: <DC 0.5 V (input voltage DC 5 V)
• Output rise time: 0.04μS
• Preservation humidity: 25% to 95% RH
• Storage temperature: -: 25 ~ +80 ° C
• Water Flow Sensor, Flowmeter: Meter Counter Instrument
• Certification: NONE
