Specifications:

• Working voltage: 5-36VDC(LV)/12-36VDC(LV-L)
• Warranty: 5 Years
• Output type: PWM constant voltage
• Output power: 40-288W(LV)/144-432W(LV-L)
• Model Number: LV
• Max. Load Power: 432
• Material: ABS
• Item Type: Dimmers
• Input signal: 0/1-10V
• Features 5: LED Controller
• Features 4: PWM dimmer
• Features 3: 0-10V Dimmer
• Features 2: LED Dimmer
• Features: 1CH 0/1-10V CV dimming controller
• Features 1: 0/1-10V dimming controller
• Dimming Range: 0-100%
• Certification: UL
• Certification: ROHS
• Certification: GS
• Certification: FCC
• Certification: EMC
• Certification: ce
• Brand Name: Lisxchda
